The DCC Packaged Air Conditioner provides energy-efficient cooling performance in one self-contained unit. This unit is suitable for ground-level or rooftop installations and horizontal or downflow applications.
Dependable compressor One of the most critical components of a packaged air conditioner is the compressor. Daikin brand DCC Packaged Air Conditioners boast high performance, high-efficiency compressors, which operate in tandem with our high efficiency coil. The coil is made of refrigeration-grade copper tubing and aluminum fins in a design that maximizes surface area. These high-quality components together cool effectively. This exceptional construction offers one of our best levels of reliability, durability, and efficiency you’ll find in a compressor.
Heaters, Curbs, and Fresh Air Dampers are sold separately for this system. Please call for pricing.
Call us at (888) 944-8684 or message us to specify the heat strip needed or if other accessories are needed.
Standard Features
- R-410A chlorine-freerefrigerant
- High-efficiency scrollcompressors
- Two-stage cooling
- Copper tube / aluminum fin coils(7½ – 10 Ton)
- Micro-Channel indoor & outdoor coils (12½ Ton)
- Power block for field wiring
- High- and low-pressure switches
- High-capacity, steel-cased filterdrier
- Heater kits with single-point entry
- 24-volt terminalstrip
- Units meet the performance outlined in Table 6.8.1-1 of ASHRAE Standard 90.1-2013
- AHRI Certified; ETL Listed
Cabinet Features
- Heavy-gauge, galvanized- steel cabinet with UV-resistant powder-paint finish
- Built-in filter rack with standard 2” filters
- Convertible airflow orientation
- Easy to service
- Full perimeter rail
- Sloped drain pan
| DCC090 ***4V***B* | |
| Cooling Capacity | |
| Total BTU/h | 88,000 |
| Sensible BTU/h | 65,100 |
| EER / IEER | 11.3 / 13.0 |
| Decibels | 82 |
| AHRI Reference #s | 7041910 |
| Evaporator Motor / Coil | |
| Motor Type | 2-speed Belt Drive |
| Indoor Nominal CFM | 3,000 |
| Indoor Motor FLA (Cooling) | 2.9 |
| Horsepower / RPM | 2 / 1740-1160 |
| Piston Size (Cooling) | 0.078 |
| Filter Size (Qty) | (4) 16 x 20 x 2 |
| Drain Size (NPT) | ¾” |
| R-410A Refrigerant Charge Cir #1 & #2 | 100 oz. |
| Evaporator Coil Face Area (ft²) | 8.9 |
| Rows Deep / Fins per Inch | 4/16 |
| Belt Drive Evap Fan Data | |
| # of Wheels (D x W) | 1 (15″ x 12″) |
| Motor Sheave / Blower Sheave | VL40 / AK74 |
| Belt | AX51 |
| Condenser Fan / Coil | |
| Quantity of Condenser Fan Motors | 2 |
| Horsepower – RPM | ¼ – 1075 |
| Fan Diameter / # Fan Blades | 22 / 4 |
| Outdoor Nominal CFM | 7,200 |
| Face Area (ft²) | 28.8 |
| Rows Deep / Fins per Inch | ‘2 X2 / 27±1 |
| Compressor Quantity / Type / Stage Compressor RLA / LRA | 2 / Scroll / 1 6.1 / 41.0 |
| Electrical Data | |
| Voltage-Phase-Frequency | 460-3-60 |
| Standard Motor Max. External Static | 1.0″ |
| Outdoor Fan HP / RLA | (2) ¼ / 0.7 |
| Min. Circuit Ampacity¹ | 18.0 |
| Max. Overcurrent Protection (amps)² | 20 |
| Entrance Power Supply | Locating |
| Entrance Control Voltage | Dimple |
| Operating Weight (lbs) | 1010 |
| Ship Weight (lbs) | 1085 |
$6,680.00
Out of stock
