(This Product Is Discontinued)
Product Features
• Check flowrator for cooling and heat pump applications
• Direct drive, multi-speed PSC blower motor
• All-aluminum evaporator coil
• Coil mounting track for quick repositioning
• Cabinet air leakage less than 2.0% at
1.0 inch H₂O when tested in accordance with ASHRAE standard 193
• Cabinet air leakage less than 1.4% at 0.5 inch H₂O when tested in
accordance with ASHRAE standard 193
• AHRI certified; ETL listed
• Rigid SmartFrame™ cabinet
• Horizontal or vertical configuration capabilities
• 21″ depth for easier attic access
• DecaBDE-free thermoplastic drain pan with secondary drain connections
• Screw-less sides and back helps to reduce condensation when installed in humid locations
• Foil-faced insulation covers the internal casing to reduce cabinet condensation
• Galvanized, leather grain-embossed finish
• Glue-less cabinet insulation retention
• Tool-less filter access
• Field Installed 3 kW – 25 kW electric heater kits available
| ARUF37D14 | |
| Nominal Ratings | |
| Cooling (Btu/h) | 36,000 |
| Piston Size | 0.072 |
| Blower | |
| Diameter | 10⅝” |
| Width | 10⅝” |
| Coil Connections | |
| Liquid | ⅜” |
| Suction | ⅞” |
| Coil Drain Connect (FPT) | ¾” |
| Electrical Data | |
| Voltage | 208/230 |
| Min Circuit Ampacity | 3.6/3.6 |
| Max. Overcurrent Device (Amps) | 15/15 |
| Minimum VAC | 197 |
| Maximum VAC | 253 |
| Blower Motor | |
| Full Load Amps (FLA) | 2.85 |
| Horsepower (HP) | ⅓ |
| Ship Weight (Lbs.) | 140 |
Are you looking for Goodman package units near me or want to shop HVAC systems, parts, and ducts for product services? Just call us at (762) 435-4822 to buy them.
$1,031.00
Out of stock
