Standard Features
• Durable, corrosion-resistant T-140 aluminized steel tubular heat exchanger
• High-efficiency two-stage scroll compressor
• Convertible airflow: horizontal or downflow application
• Multi-speed ECM indoor blower motor
• Copper tube/aluminum fin condenser coil
• All-aluminum evaporator coil on 2- to 4-ton units
• Aluminum-copper evaporator coil on 5-ton units
• Power-assisted combustion
• Loss-of-charge protection & high-pressure switch
• AHRI Certified; ETL Listed
• Two-stage gas valve; natural gas with easy conversion to propane with accessory kit
• Direct spark ignition system includes a microproces- sor-based control for the entire ignition sequence
• All blower operation and all safety circuits complete with self-diagnostics
• All models comply with California
Low NOx emission standards
• For installation in California’s South Coast Air Quality Management District (SCAQMD) only:
This furnace does not meet the SCAQMD Rule 1111 14 ng/J NOx emission limit, and thus is subject to a mitigation fee of up to
$450. This furnace is not eligible for the SCAQMD Clean Air Furnace Rebate Program:
www.CleanAirFurnaceRebate.com.
Cabinet Features
• Fully insulated heavy-gauge, zinc-coated steel cabinet with UV-resistant powder-paint finish
• Aluminum foil-facing internal insulation reinforced with fiberglass scrim
• Convenient access panels
• One roof curb fits 2-4 ton units
• Bottom, 2” high base rails for easier handling
• 2-4 ton models fit a standard-size pick-up truck
• When properly anchored, meets the 2010 Florida Building Code unit integrity requirements for hurricane-type winds (Anchor bracket kits available.)
• Meets cabinet air leakage requirements when tested in accordance with ASHRAE standard 193
| GPG1630080M41 | |
| Cooling Capacity | |
| Total BTU/h | 28,600 |
| Sensible BTU/h | 21,800 |
| SEER / EER | 15.5 / 12.0 |
| Decibels | 76 |
| AHRI Reference #s | 8082383 |
| Heating Capacity (BTU/h) | |
| High-Fire Input / Output | 80,000 / 62,000 |
| Low-Fire Input / Output | 60,000 / 47,000 |
| AFUE | 81 |
| Temperature Rise Range | 35 – 65 |
| No. of Burners | 4 |
| Orifice Size (Natural/Propane) | 45 / 1.25MM |
| Evaporator Motor | |
| Type | ECM |
| Wheel (D x W) | 10” x 9” |
| Indoor Nominal CFM | 950 |
| Motor Speed Tap (Cooling) | T3 L / T4 H |
| RPM/Amps (Cooling) | 1050 / 3.8 |
| Horsepower | 1/2 |
| Evaporator Coil | |
| Face Area (ft²) | 4.3 |
| Rows Deep/Fins per Inch | 3 / 14 |
| Piston Size (Cooling) | TXV |
| Filter Size (ft²) | 4.3 |
| Drain Size (NPT) | ¾” |
| Refrigerant Charge (oz.) | 70 |
| Condenser Fan / Coil | |
| Horsepower – RPM | 1/4 – 830 |
| Diameter / # of Blades | 22” / 3 |
| Outdoor Nominal CFM | 2,200 |
| Face Area (ft²) | 8.7 |
| Rows Deep/Fins per Inch | 2 / 27 |
| Compressor | |
| Quantity / Type / Stage | 1 / Scroll / 2 |
| Compressor RLA/LRA | 13.1 / 73.0 |
| Electrical Data | |
| Voltage-Phase (Frequency 60Hz) | 208/230-1 |
| Indoor Blower FLA/LRA | 3.8 |
| Outdoor Fan FLA/LRA | 1.5 / 3.0 |
| Total Unit Amps | 18.4 |
| Min. Circuit Ampacity ¹ | 21.7 |
| Max. Overcurrent Protection ² | 30 amps |
| Entrance Size Power Supply | 1⅛” |
| Entrance Size Control Voltage | ⅞” |
| Operating / Ship Weights (lbs) | 397 / 407 |
| Energy Star® Certified | NO |
$4,913.00
Out of stock
