Standard Features
• Energy-efficient compressor
• Multi-speed ECM indoor blower motor
• Convertible airflow: horizontal or downflow application
• Copper tube/aluminum fin condenser coil
• All-aluminum evaporator coil
• Totally enclosed, permanently lubricated condenser fan motor
• 5 kW to 20 kW electric heat kit available as a field-installed option
• AHRI Certified; ETL Listed
| Â | GPC1460M41 |
| Cooling Capacity | Â |
| Total BTU/h | 56,000 |
| Sensible BTU/h | 41,000 |
| SEER / EER | 14 / 11.0 |
| Decibels | 80.2 |
| AHRI Numbers | 7513343 |
| Evaporator Motor | Â |
| Type | ECM |
| Nominal Cooling CFM | 1,700 |
| Wheel (DxW) | 10 x 9 |
| No. of Speeds | 5 |
| Horsepower – RPM | 1.0 |
| Evaporator Coil | Â |
| Face Area (ft²) | 6.17 |
| Rows Deep/ Fin per Inch | 4/ 14 |
| Drain Size (NPT) | ¾” |
| Refrigerant Charge (oz.) | 177 |
| Condenser Fan / Coil | Â |
| Horsepower – RPM | â…“ – 1120 |
| Fan Diameter / # Fan Blades | 22 / 3 |
| Face Area (ft²) | 20.67 |
| Rows Deep/ Fins per Inch | 2 / 16 |
| Compressor | Â |
| Quantity | 1 |
| Type | Scroll |
| Stage | Single |
| Electrical Data | Â |
| Voltage-Phase | 208/230-1 |
| Compressor RLA/LRA | 25.0 / 134 |
| Indoor Blower FLA | 7.0 |
| Outdoor Fan FLA / LRA | 2.0 / 4.4 |
| Total Unit Amps | 34.0 |
| Min. Circuit Ampacity¹ | 40.3 |
| Max. Overcurrent Protection² | 60 amps |
| Ship Weight (lbs) | 458 |
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
Free Shipping
$4,667.00
-
