Standard Features
• Energy-efficient compressor
• Single-speed condenser fan motor
• Factory-installed filter drier
• Copper tube/aluminum fin coil
• Service valves with sweat connections
and easy-access gauge ports
• Contactor with lug connection
• Ground lug connection
• AHRI Certified; ETL Listed
Cabinet Features
• Heavy-gauge galvanized-steel cabinet with a louvered sound control top
• Attractive Architectural Gray powder-paint finish with 500-hour salt-spray approval
• Steel louver coil guard
• Top and side maintenance access
• Single-panel access to controls with space
provided for field-installed accessories
• When properly anchored, meets the 2010 Florida
Building Code unit integrity requirements for hurri-
cane-type winds (Anchor bracket kits available.)
| GSX140361 | |
| Capacities | |
| Nom Cool (BTU/h) | 36,000 |
| SEER/EER | 14 / 12 |
| Decibels | 73 |
| Compressor | |
| RLA | 14.1 |
| LRA | 77 |
| Condenser Fan Motor | |
| Hp | 1/6 |
| FLA | 0.95 |
| Refrigeration System | |
| Refrigerant Line Size ¹ | |
| Liquid Line Size (“O.D.) | ⅜" |
| Suction Line Size (“O.D.) | ⅞" |
| Refrigerant Connection Size | |
| Liquid Valve Size (“O.D.) | ⅜" |
| Suction Valve Size (“O.D.) ² ³ | ¾" |
| Valve Type | Sweat |
| Charge | 81 |
| Included piston: | 0.068 |
| Electrical Data | |
| Voltage-Phase (60 Hz) | 208/230-1 |
| Minimum Circuit Ampacity ⁴ | 18.6 |
| Max. Overcurrent Protection ⁵ | 30 amps |
| Min/Max Volts | 197/253 |
| Conduit | ½" or ¾" |
| Equipment Weight Shipping Weight | 162 180 |
Standard Features
• All-Aluminum evaporator coil
• Optimized for use with R-410A refrigerant
• Some models suitable for use with
R-410A or R-22 refrigerant
• CAPT models feature factory-installed thermal expansion valves for cool- ing and heat pump applications
• Check flowrator for cooling and heat pump applications
• Vertical and horizontal models available
• 21″ depth for easier attic access
• Foil-faced insulation covers the internal casing to reduce cabinet condensation
• Galvanized, leather grain-embossed finish
• Rust resistant, thermoplastic drain pans featuring a low water-retention design
• DecaBDE-free thermoplastic drain pan with secondary drain connections
• UV-resistant drain pan
• AHRI certified; ETL listed
| Model | Unit Dimensions | Nominal Tons | Connection | Piston Size* | Ship Weight (lbs) | |||
| W | D | H | Liquid | Suction | ||||
| CAPF3137B6 | 17½" | 21⅛" | 30" | 2½-3 | ⅜" | ¾" | 0.071 | 53 |
Standard Features
• Heavy-duty aluminized-steel dual- diameter tubular heat exchanger
• Single-stage gas valve
• Durable Hot-surface igniter
• Quiet, single-speed draft induced
• Self-diagnostic control board
• Color-coded low-voltage terminals
• Multi-speed ECM blower motor
• California Low NOx emissions models available
• Can no longer be installed in California’s South Coast Air Quality Management District (SCAQMD)
on or after October 1, 2019.
• AHRI Certified; ETL Listed
Cabinet Features
• Installation:
– GMES80-upflow, horizontal left or right
– GCES80- downflow, horizontal left or right
• Convenient left or right connection
for gas and electrical service
• Heavy-gauge steel cabinet with durable baked-enamel finish
• Foil faced insulated heat exchanger
| GMES800403A | |
| Heating Capacity | |
| Input | 40,000 |
| Natural Gas Output | 32,000 |
| LP Gas Output | 32,000 |
| AFUE ¹ | 80 |
| Available AC @ 0.5” ESP | 3 |
| Temperature Rise Range (°F) | 25-55 |
| Circulator Blower | |
| Size (D x W) | 10" x 6" |
| Horsepower @1075 RPM | 0.5 |
| Speed | 5 |
| Vent Diameter ² | 4" |
| No. of Burners | 2 |
| Electrical Data | |
| Min. Circuit Ampacity ³ | 8.7 |
| Max. Overcurrent Device (amps) ⁴ | 15 |
| Ship Weight (lbs) | 86 |
$2,897.00
Out of stock
