24,000 BTU 17 SEER Single Zone Heat Pump Daikin Wall Mounted Mini-Split RXB24AXVJU FTXB24AXVJU

Storewide Sale

Add To Cart To See Savings

24,000 BTU 17 SEER Single Zone Heat Pump Daikin Wall Mounted Mini-Split RXB24AXVJU FTXB24AXVJU

The Daikin 17 series single-zone inverter wall-mounted systems provide energy efficiency and comfort control with an affordable, cost-saving solution.17 series single-zone inverter wall-mounted units are simple to install. The curved contour design blends to match with any home décor and is ideal for single room enhancements, spaces requiring additional heating or cooling, and additions. The air direction and flow rate are adjustable so that the air will not blow directly at people in the room.

Standard Features
● Inverter Compressor
● Precharged for up to 24.6 ft of Liquid Line
● Self Diagnostics with Digital Display
● Econo+ Mode / Dry Function / Powerful Mode
● Auto Fan Speed Control
● Anti-Corrosion Treatment on Heat Exchanger
● Wireless IR Remote Controller
● Indoor/Outdoor Unit Quiet Operation
● Auto Restart after Power Failure
● Max Piping (09/12 MBH): 65.625′ Length, 32.8′ Height 165′
● Max Piping (18/24 MBH): 98.4′ Length, 32.8′ Height 55′
● NO LOW AMBIENT OPERATION

Premium comfort features:
›› Energy Efficient – Up to 17 SEER / Up to 9.0 HSPF / Up to 11.5 EER for efficient cooling and heating
operation and reduced operating costs compared to conventional lower-efficiency systems.

››Heating Range 5° – 65° F*
››Cooling Range 50° – 115° F

Ideal solution for:
›› Renovations, remodeling and new construction
›› A perfect alternative to noisy and inefficient window or through-the-wall air conditioner units
›› Sun rooms, basements, attics, garages, hot or cold rooms, and more
›› Rooms where floor space comes at a premium or is not available for other application
›› Ceiling void or attic does not allow for a viable duct run option
›› Cooling Only models are an excellent value for space not requiring heating

Powerful Operation – Pushing the POWERFUL button on the remote control gives you a boost in cooling or heating power for a 20-minute period, even if the unit is already operating at high capacity.

ECO+ – An intelligent feature that ensures optimum energy consumption while fulfilling basic human comfort needs. Once activated, set temperature
will be adjusted automatically to an optimum energy consumption level.

Blue Fin Protection – The hydrophilic coated fin ensures the condensate water moves easily to the drain pan — thus enhancing the cleanliness and
lifespan of the cooling coil.

Titanium Apatite Photocatalytic Air Purifying
Filter – This filter combines the air-purifying filter and titanium apatite photocatalytic deodorizing filter in a single highly effective unit.

FTXB24AXVJU RXB24AXVJU
Unit size (BTU) 24000 Unit size (BTU) 24000
Airflow Rate (Cooling/Heating CFM) Airflow Rate (CFM)
High 555/580 High 1794
Medium 486/486 Sound (dBA)
Low 405/405 H 52
Sound (dBA) Compressor
H 47 Type Hermetically Sealed Swing
M 44 Refrigerant R-410A
L 41 Factory Charge (lbs) 3.20
Dimensions Refrigerant Oil PVE (FVC50K)
H 12⅝ Dimensions
W 46⅛ H 29¹¹⁄₁₆
D W 33¹¹⁄₁₆
Electrical [(208/230)/60/1] D 12¹⁵⁄₁₆
Indoor Fan Motor (FLA) .24 Electrical [(208/230)/60/1]
Indoor Fan Motor (W) 40 Outdoor fan motor (FLA) .50
System MCA 16.2 Outdoor fan motor (W) 61
System MFA 20 Compressor (RLA) 6.75
Piping System MCA 13.2
Liquid (in) ¼ System MFA 20
Gas (in) Piping
Drain (in) ¾ Liquid (in) ¼
Max Interunit Piping Length (ft) 98.4 Gas (in)
Max Interunit Height Difference (ft) 32.8 Drain (in) ¾
Chargless Piping Length (ft) 24.6 Max Interunit Piping Length (ft) 98.4
Charging Ratio (Oz / Ft) .21 Max Interunit Height Difference (ft) 32.8
Rated Cooling Conditions 80° F DB/67° F WB Chargless Piping Length (ft) 24.6
Weight (lbs) 31 Charging Ratio (Oz / Ft) .21
Efficiency (Cooling) Performance
SEER 17 Cooling (Btu/hr)
EER 11 Rated (min/max) 21200 (6000-22200)
Efficiency (Heating) Sensible @ Ahri 15116
HSPF 9 Operating Range 50° F - 115° F
COP 3.68 Rated Cooling Conditions 95°F DB/75° F WB
Weight (lbs) 97
Heating (Btu/hr)
47° Rated 21200 (4100-27300)
17° 11800
10381
Operating Range 5° F - 65° F
Rated Heating Conditions 47°F DB/43° F WB
Weight (lbs) 97
